Any issues with camber, stretched tires or rubbing?
Like blnewt said, my tire size on that size wheel is standard. I have no rubbing issues. As for camber, I'm running around -2.2/-2.3 in the rear. I may live with that or I may try to have it pulled closer to in reference range. Front camber is within referenced range.
Wheel Brand & Model- ESR SR07
Wheel Sizes, including offset- 19x9.5 all around, +25 up front, +35 out back
Tire sizes- 255/40R19 all around
Wheel weight (if known)- 27lb I believe
Suspension: Tein Basis Zs at 26.25" FTG all around
Big Brake clearance- NO- you will need a 10mm spacer.
If Spacers are being used- yes, 10mm up front- you will need new studs
My advice.... go 19x8.5 + 245s all around. Those will fit the BBK, be lighter and fit about the same with a spacer
Last edited by future62; Oct 15, 2017 at 05:37 PM.
I know very little about proper rim fitment relating to offset. If I get a 19 x 9.5 TSW Nurburgring 41 offset with 245/45/19 tires would I need spacers and would these fit ok and look good as is? Found an amazing deal for them on Craigslist. Struggling to decide what rims and rim color to go with due to owning a "coveted" 09 Sahara Sandstone. I'm thinking the matte bronze would go well with them and I'm not sure I've seen another posted on here with that combo.
I know very little about proper rim fitment relating to offset. If I get a 19 x 9.5 TSW Nurburgring 41 offset with 245/45/19 tires would I need spacers and would these fit ok and look good as is? Found an amazing deal for them on Craigslist. Struggling to decide what rims and rim color to go with due to owning a "coveted" 09 Sahara Sandstone. I'm thinking the matte bronze would go well with them and I'm not sure I've seen another posted on here with that combo.
Those will fit fine, very good FWIW Will not need spacers but if they don't have hub ring adapters I would recommend them. The Infniti hub bore is 66.1mm and most aftermarket wheels have oversized bores so they can fit more vehicles. Just need to confirm the hub bore on the TSWs, 73.1mm is pretty common. This will eliminate or greatly reduce any high speed vibration caused by loose fit at the hub/wheel mount. Aluminum ones on ebay are better than the plastic ones that ship out w/ most wheels. Here's one example~ https://www.ebay.com/i/321944710953?chn=ps&dispItem=1
Those will fit fine, very good FWIW Will not need spacers but if they don't have hub ring adapters I would recommend them. The Infniti hub bore is 66.1mm and most aftermarket wheels have oversized bores so they can fit more vehicles. Just need to confirm the hub bore on the TSWs, 73.1mm is pretty common. This will eliminate or greatly reduce any high speed vibration caused by loose fit at the hub/wheel mount. Aluminum ones on ebay are better than the plastic ones that ship out w/ most wheels. Here's one example~ https://www.ebay.com/i/321944710953?chn=ps&dispItem=1
I got them installed late last night and they seem to fit fine. The TPMS light is now on so clearly the Q50 TPMS sensors aren't going to work. Luckily I got some of the older G35 TPMS sensors in the deal as well as the hub rings but I need to get them installed. I also got a 5th rim. As best I can tell, this package would've been $2200+ brand new. A couple of the rims have curb rash but it is minor. I'm thinking I got a pretty good deal for $600. Pics to follow.
I got them installed late last night and they seem to fit fine. The TPMS light is now on so clearly the Q50 TPMS sensors aren't going to work. Luckily I got some of the older G35 TPMS sensors in the deal as well as the hub rings but I need to get them installed. I also got a 5th rim. As best I can tell, this package would've been $2200+ brand new. A couple of the rims have curb rash but it is minor. I'm thinking I got a pretty good deal for $600. Pics to follow.
Nice deal! Yeah, that TPMS compatibility is a PITA.
Nice deal! Yeah, that TPMS compatibility is a PITA.
I figured once I have my winter wheels on, I'll get the tires unmounted and the correct TPMS installed. I also have my choice of the best 4 rims since I got 5, so I'll be switching out the one with the most rash during the process. Do you know if the torque specs are the same on a TSW rim? I couldn't find anything on their website and went with 100 ft/lbs for now.
I figured once I have my winter wheels on, I'll get the tires unmounted and the correct TPMS installed. I also have my choice of the best 4 rims since I got 5, so I'll be switching out the one with the most rash during the process. Do you know if the torque specs are the same on a TSW rim? I couldn't find anything on their website and went with 100 ft/lbs for now.
I'd back it off a bit, torque should be in the 80-85 ft. lb range.
That's pretty out there, man. Pretty creative stuff, but to be expected from a Designer of Planets.
Will not need spacers but if they don't have hub ring adapters I would recommend them. The Infniti hub bore is 66.1mm and most aftermarket wheels have oversized bores so they can fit more vehicles. Just need to confirm the hub bore on the TSWs, 73.1mm is pretty common. This will eliminate or greatly reduce any high speed vibration caused by loose fit at the hub/wheel mount. Aluminum ones on ebay are better than the plastic ones that ship out w/ most wheels. Here's one example~
