20" wheel pic thread
#1
20" wheel pic thread
Only 1 post per set of wheels
Only max of 4 pics please and preferably 1 of the wheel, 1 of the whole side of car, one from the front at an angle, and one shot down the side showing the fit at the fender. These are just guideline suggestions, but would be good to include as many of those views as you can in your 4 shots.
Please provide as much info as you can such as~
***Please keep ANY replies limited to specific questions about the wheels. To keep this thread as useful and easy to navigate as possible, if you like the wheels send a PM to the OP or push the thanks button. Really appreciate if you guys/gals can stick to these guidelines.
Thanks for your contributions, hopefully this can become a concise and useful folder for those wanting to see what's out there, and how they look on our cars
Only max of 4 pics please and preferably 1 of the wheel, 1 of the whole side of car, one from the front at an angle, and one shot down the side showing the fit at the fender. These are just guideline suggestions, but would be good to include as many of those views as you can in your 4 shots.
Please provide as much info as you can such as~
- Wheel Brand & Model
- Wheel Sizes, including offset
- Tire sizes
- Wheel weight (if known)
- Big Brake clearance
- If Spacers are being used
***Please keep ANY replies limited to specific questions about the wheels. To keep this thread as useful and easy to navigate as possible, if you like the wheels send a PM to the OP or push the thanks button. Really appreciate if you guys/gals can stick to these guidelines.
Thanks for your contributions, hopefully this can become a concise and useful folder for those wanting to see what's out there, and how they look on our cars
#2
The Steering Wheel Guy
iTrader: (12)
This is my forum debut for my new wheels, and what better place to start then the first post of our great new thread!
Vossen VFS1 - Matte Graphite
Wheels:
Tires:
Miscellaneous Information:
Vossen VFS1 - Matte Graphite
Wheels:
- Front: 20x9.5" +25 (Mid Concave)
- Rear:20x10.5" +40 including 5mm hubcentric spacer (Deep Concave)
Tires:
- Front: 245/35R20 Continental DWS06
- Rear: 285/30R20 Continental DWS06
Miscellaneous Information:
- 25.8lbs for the 20x10.5"
- Clears the BBK without spacers
- 5mm hubcentric spacers are used in the back
- Lowered on Eibach ProKit, front and rear SPC camber kits, camber is within OEM spec but on the far negative side. No rubbing - my rear fender liner has been trimmed previously. My bumper bracket is not trimmed.
Last edited by Ryne; 06-21-2016 at 01:27 PM.
#4
Administrator
iTrader: (9)
When I joined this forum, Vossens were appreciated more so than the last few years. I don't know why... don't really care, because those VFS1's are gorgeous, IMO. That finish is so appealing on your Coupe. I love everything about them, (except the location of the tire stem. That's a real b1tch to access for a 10-spoke wheel.)
The following users liked this post:
kennyz424 (06-18-2016)
The following 2 users liked this post by J.Tilley:
blnewt (06-18-2016),
flipmodeq60ipl (04-18-2019)
#6
Registered Member
iTrader: (2)
20" KMC Rockstar
(My Summer Set)
Square setup.
Hankook Ventus V12 Evo
Weight 26 lbs.
245/35ZR20
VENTUS V12 EVO2 K120 Summer / Performance Tires (1015365) by Hankook®. 245/35ZR20
Brand KMC Wheels
Model Rockstar Car
Item Weight 32.6 pounds
Product Dimensions 20 x 8 x 20 inches
Item model number KM77528001742
Construction 1 Piece
Offset 42 millimeters
Backspace 6.15 inches
Bore Diameter 72.6 millimeters
Real life weights turned out ~+4lbs per corner over 19"stock wheels and tires.
Validated on scale:
KMC Rockstar 20" x8 wheel w/Hankook Ventus V12 Evo 245/35ZR20
54.2lbs wheel and tire
Stock Inf Sport 19x8.5 w/ Continental Extreme Contact DWS06
245/45ZR19
50.0lbs wheel and tire.
I plan to drop it to remove the wheel gap. Will decide on spacers after I see how it sits.
(My Summer Set)
Square setup.
Hankook Ventus V12 Evo
Weight 26 lbs.
245/35ZR20
VENTUS V12 EVO2 K120 Summer / Performance Tires (1015365) by Hankook®. 245/35ZR20
Brand KMC Wheels
Model Rockstar Car
Item Weight 32.6 pounds
Product Dimensions 20 x 8 x 20 inches
Item model number KM77528001742
Construction 1 Piece
Offset 42 millimeters
Backspace 6.15 inches
Bore Diameter 72.6 millimeters
Real life weights turned out ~+4lbs per corner over 19"stock wheels and tires.
Validated on scale:
KMC Rockstar 20" x8 wheel w/Hankook Ventus V12 Evo 245/35ZR20
54.2lbs wheel and tire
Stock Inf Sport 19x8.5 w/ Continental Extreme Contact DWS06
245/45ZR19
50.0lbs wheel and tire.
I plan to drop it to remove the wheel gap. Will decide on spacers after I see how it sits.
Last edited by bikezilla; 06-24-2016 at 02:55 PM.
The following users liked this post:
blnewt (06-24-2016)
#7
Premier Member
iTrader: (1)
Just now saw this thread thanks to Blnewt's sig.
Here are my Blaque Diamond rims.
Specs are as followed
8.5 +35 & 10" +38 (thanks again Blnewt)
Not sure about the weight.
Tires are Toyo Proxy T1 sports 245/35/20 & 285/30/20
Clears BBK
Stock suspension I get occasional rubbing in the rear when hitting dips at speed. Doesn't concern me.
Here are my Blaque Diamond rims.
Specs are as followed
8.5 +35 & 10" +38 (thanks again Blnewt)
Not sure about the weight.
Tires are Toyo Proxy T1 sports 245/35/20 & 285/30/20
Clears BBK
Stock suspension I get occasional rubbing in the rear when hitting dips at speed. Doesn't concern me.
The following users liked this post:
blnewt (08-18-2016)
Trending Topics
#12
Registered Member
G37S Aggressive Concave Wheels
Niche Misano M117 Anthracite
Wheels:
Front: 20x10.5 +30
Rear:20x10.5" +30
Tires:
Front: 255/30-20 Accelera Phi
Rear: 255/30-20 Accelera Phi
Modifications done for fitment:
Negative Camber mostly on the rear
8mm spacers front and rear (Needed for front caliper clearance)
Tein Street Advance Coilovers
Front and rear fender liners have been trimmed.
Pictures taken while testing fitment and suspension adjustment.
Wheels:
Front: 20x10.5 +30
Rear:20x10.5" +30
Tires:
Front: 255/30-20 Accelera Phi
Rear: 255/30-20 Accelera Phi
Modifications done for fitment:
Negative Camber mostly on the rear
8mm spacers front and rear (Needed for front caliper clearance)
Tein Street Advance Coilovers
Front and rear fender liners have been trimmed.
Pictures taken while testing fitment and suspension adjustment.
The following users liked this post:
r2dmax (02-07-2018)
#13
Registered Member
Deep Concave Stance
NICHE MISANO - M117 Anthracite
Wheels:
Front: 20x10.5 +30
Rear: 20x10.5 +30
Tires:
Front: 255/30-20 Accelera PHI
Rear: 255/30-20 Accelera PHI
Modifications Done:
8mm hub centric spacers all around (needed to clear front calipers on S model only)
Lowered on Tein Flex Z coil-overs
Hotchkis Sport Suspension sway bars
Negative camber needed to clear
Front and Rear fender liner trimmed
Fenders Rolled
No Rubbing
Let me know if you have any additional questions regarding fitment or specs.
Wheels:
Front: 20x10.5 +30
Rear: 20x10.5 +30
Tires:
Front: 255/30-20 Accelera PHI
Rear: 255/30-20 Accelera PHI
Modifications Done:
8mm hub centric spacers all around (needed to clear front calipers on S model only)
Lowered on Tein Flex Z coil-overs
Hotchkis Sport Suspension sway bars
Negative camber needed to clear
Front and Rear fender liner trimmed
Fenders Rolled
No Rubbing
Let me know if you have any additional questions regarding fitment or specs.
